Specifikationer
Allmänt
Sokkel
AM4
Formfaktor
ATX
Chipsæt
B550 (AMD 3-5000 series)
Kompatible processorer
AMD Ryzen™ 5000 Series/4000 G-Series/3000 Series Desktop Processors
WiFi
Nej
Antal RAM slots
4
RAM Teknologi
DDR4
RAM
Ram Bus Clock
4600(O.C)/4400(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3333(O.C.)
3200/3000/2800/2666/2400/2133 MHz Un-buffered Memory
3200/3000/2800/2666/2400/2133 MHz Un-buffered Memory
Maks. RAM kapacitet
128 GB
Interface
Ekspansionsåbninger
1 x PCIe 4.0 x16 (x16 mode)
1 x PCIe 3.0 x16 (x16 mode)
3 x PCIe 3.0 x1
1 x PCIe 3.0 x16 (x16 mode)
3 x PCIe 3.0 x1
Grænseflade (lagring)
1 x M.2 Socket 3, with M key, type 2242/2260/2280/22110(SATA & PCIe 4.0 x4 mode)
1 x M.2 Socket 3, with M Key, Type 2242/2260/2280/22110(PCIE 3.0 x4 and SATA modes)
6 x SATA 6Gb/s port(s)
1 x M.2 Socket 3, with M Key, Type 2242/2260/2280/22110(PCIE 3.0 x4 and SATA modes)
6 x SATA 6Gb/s port(s)
Interne interfaces
1 x CPU Fan connector(s)
1 x CPU OPT Fan connector
3 x Chassis Fan connector
1 x AIO_PUMP connector
2 x Aura RGB Strip Headers
1 x Addressable Gen 2 header
1 x USB 3.2 Gen 1(up to 5Gbps) connector
2 x USB 2.0 connector(s)
1 x SPI T
1 x CPU OPT Fan connector
3 x Chassis Fan connector
1 x AIO_PUMP connector
2 x Aura RGB Strip Headers
1 x Addressable Gen 2 header
1 x USB 3.2 Gen 1(up to 5Gbps) connector
2 x USB 2.0 connector(s)
1 x SPI T
Interfaces
1 x DisplayPort
1 x HDMI
1 x LAN (2.5G) port
2 x USB 3.2 Gen 2 (1 x Type-A+1 x USB Type-C®)
4 x USB 3.2 Gen 1 Type-A
2 x USB 2.0 (one port can be switched to USB BIOS FlashBack™)
1 x Optical S/PDIF out
5 x Audio jack
1 x HDMI
1 x LAN (2.5G) port
2 x USB 3.2 Gen 2 (1 x Type-A+1 x USB Type-C®)
4 x USB 3.2 Gen 1 Type-A
2 x USB 2.0 (one port can be switched to USB BIOS FlashBack™)
1 x Optical S/PDIF out
5 x Audio jack
Strømkontakter
1 x 24-pin EATX Power connector
1 x 8-pin EATX 12V Power connectors
1 x 8-pin EATX 12V Power connectors
Misc.
Dybde
244
Bredde
305
Tilbehør
User´s manual
I/O Shield
2 x SATA 6Gb/s cable(s)
1 x Supporting DVD
1 x TUF Gaming Sticker
1 x TUF Certification card
1 x M.2 SSD screw package
1 x M.2 Rubber Package
I/O Shield
2 x SATA 6Gb/s cable(s)
1 x Supporting DVD
1 x TUF Gaming Sticker
1 x TUF Certification card
1 x M.2 SSD screw package
1 x M.2 Rubber Package
