Specifikationer
Allmänt
Sokkel
AM4
Formfaktor
M-ATX
Chipsæt
A520 (AMD 3-5000 series)
Kompatible processorer
AMD Ryzen™ 5000 Series/ 4000 G-Series/ 3000 Series Desktop Processors
WiFi
Nej
Antal RAM slots
2
RAM Teknologi
DDR4
RAM
Ram Bus Clock
4600(O.C)/4400(O.C)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)
3466(O.C.)/3333(O.C.)/3200/3000/2800/2666/2400/2133 MHz Un-buffered Memory
3466(O.C.)/3333(O.C.)/3200/3000/2800/2666/2400/2133 MHz Un-buffered Memory
Maks. RAM kapacitet
64 GB
Interface
Ekspansionsåbninger
1 x PCIe 3.0 x16 (x16 mode)
2 x PCIe 3.0 x1
2 x PCIe 3.0 x1
Grænseflade (lagring)
1 x M.2 Socket 3, with M Key, Type 2242/2260/2280 (PCIE 3.0 x4 and SATA modes)
4 x SATA 6Gb/s port(s)
4 x SATA 6Gb/s port(s)
Interne interfaces
1 x CPU Fan connector
1 x Chassis Fan connector
1 x USB 3.2 Gen 1(up to 5Gbps) Port
2 x USB 2.0 connector
1 x SPI TPM header
1 x S/PDIF out header
1 x Front panel audio connector(s) (AAFP)
1 x Clear CMOS jumper
1 x System panel con
1 x Chassis Fan connector
1 x USB 3.2 Gen 1(up to 5Gbps) Port
2 x USB 2.0 connector
1 x SPI TPM header
1 x S/PDIF out header
1 x Front panel audio connector(s) (AAFP)
1 x Clear CMOS jumper
1 x System panel con
Interfaces
1 x PS/2 keyboard/mouse combo port
1 x D-Sub
1 x HDMI
1 x LAN (RJ45) port
4 x USB 3.2 Gen 1 (blue) Type-A
2 x USB 2.0
3 x Audio jack(s)
1 x D-Sub
1 x HDMI
1 x LAN (RJ45) port
4 x USB 3.2 Gen 1 (blue) Type-A
2 x USB 2.0
3 x Audio jack(s)
Strømkontakter
1 x 24-pin EATX Power connector(s)
1 x 8-pin EATX 12V Power connectors
1 x 8-pin EATX 12V Power connectors
Misc.
Dybde
221
Bredde
226
Tilbehør
User's manual
I/O Shield
2 x SATA 6Gb/s cable
1 x Supporting DVD
1 x M.2 SSD screw package(s)
I/O Shield
2 x SATA 6Gb/s cable
1 x Supporting DVD
1 x M.2 SSD screw package(s)
