Specifikationer
Allmänt
Sokkel
AM5
Formfaktor
ITX
Chipsæt
B650 (AMD 7000)
Kompatible processorer
AMD Socket AM5 for AMD Ryzen™ 7000 Series Desktop Processors*
WiFi
Ja
Antal RAM slots
2
RAM Teknologi
DDR5
RAM
Ram Bus Clock
2x DIMM, Max. 64GB, DDR5 7600(OC)/ 7466(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/
6200(OC)/ 6000(OC)/ 5800(OC)/ 5600/ 5400/ 5200/ 5000/ 4800 Non-ECC, Un-buffered Memory
6200(OC)/ 6000(OC)/ 5800(OC)/ 5600/ 5400/ 5200/ 5000/ 4800 Non-ECC, Un-buffered Memory
Maks. RAM kapacitet
64 GB
Interface
Ekspansionsåbninger
1x PCIe 5.0 x16 slot
Grænseflade (lagring)
2x M.2 slots
4x SATA 6Gb/s ports*
4x SATA 6Gb/s ports*
Interne interfaces
1x 4-pin CPU Fan header
1x 4-pin Chasis Fan header
1x 4-pin AIO Pump header
1x USB 3.2 Gen 2 connector (supports USB Type-C®)
1x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports
1x USB 2.0 headers support additional 2 USB 2.0
1x 4-pin Chasis Fan header
1x 4-pin AIO Pump header
1x USB 3.2 Gen 2 connector (supports USB Type-C®)
1x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports
1x USB 2.0 headers support additional 2 USB 2.0
Interfaces
1x USB 3.2 Gen 2x2 port (1 x USB Type-C®)
4x USB 3.2 Gen 1 ports (3 x Type-A +1 x USB Type-C®)
3x USB 2.0 ports (3 x Type-A)
1x HDMI® port
1x DisplayPort
1x Wi-Fi Module
1x Intel® 2.5Gb Ethernet
5x Audio jacks
4x USB 3.2 Gen 1 ports (3 x Type-A +1 x USB Type-C®)
3x USB 2.0 ports (3 x Type-A)
1x HDMI® port
1x DisplayPort
1x Wi-Fi Module
1x Intel® 2.5Gb Ethernet
5x Audio jacks
Strømkontakter
1x 24-pin Main Power connector
1x 8-pin +12V Power connector
1x 8-pin +12V Power connector
Misc.
Dybde
17
Bredde
17
Tilbehør
2x SATA 6Gb/s cables
1x ROG USB2.0 splitter cable
1x Panel cable
1x Thermal pad for M.2
1x ASUS Wi-Fi moving antennas
1x Cable ties package
1x M.2 Rubber Package
2x Screw packages for M.2 SSD
1x M.2 bracket
1x ROG key chain
1x ROG USB2.0 splitter cable
1x Panel cable
1x Thermal pad for M.2
1x ASUS Wi-Fi moving antennas
1x Cable ties package
1x M.2 Rubber Package
2x Screw packages for M.2 SSD
1x M.2 bracket
1x ROG key chain
